RFID Card Readers – N400
N400 Readers are part of viAccess platform for adaptable & interoperable access control systems. This
all-metal vandal proof reader with an elegant design is compatible with all access control systems,
oering versatility and scalability to secure your physical access control today and into the future.
Including 125 kHz(EM/HID), 13.56 MHz(Mifare/NFC) credentials, with NFC mobile credentials, to power
your systems and user experiences. Equipped with OSDP secure channel, it makes migration to advanced
credentials security easy without having to replace existing credentials, opening opportunities for new and more advanced
credentials and security options. Organizations using the N400 Readers can develop a credentials strategy that better
accommodates dierent user proles, combining soft & hard credentials in order to reach optimized cost vs. functionality across the
dierent sites & points of access.
Product Description
||MA I N F E AT U R E S
• Selectable Wiegand output formats using the Hardware Con guration Tool
• Mounting options include US gangbox and UK/Asia gangbox.
• NFC Smartphone is supported
• Read the CSN from the following smart cards:
– IS014443A – MIFARE Ultralight Nano / Ultralight EVI / Ultralight C
– MIFARE Classic / Classic EVI
– MIFARE Plus S / SE / X / EVI
– MIFARE DESFire EVI / EV2
|| S P E C I F I C AT I O N S
• • Read Range: 125 KHz: 5 cm, 13.56 MHz: 2 cm
• • Reader Data Output Formats: CSN Wiegand 26/37 Bit and OSDP
• • Zinc Alloy case, Weather-resistant IP68, Vandal-proof IK10
• • Operating Voltage Range: 12 VDC with 10% tolerance
• • Idle Current at 12 VDC: Maximum 35 mA
• • Operating Temperature Range: -20 °C to 50 °C
• • Operating Humidity Range: to 95% (non-condensing)
• • Dimensions (hxwxd): 103x48x22 mm (S Model) / 120x83x22.5 mm (Max Model)
|| O P T I O N S
• Open Standard Device Protocol (OSDP)
• Support IS015693 – HID iClass, PicoPass, iCode, LEGIC
• Support IS018092 – SONY Felica
- New and powerful engine
- New and powerful engine
- New and powerful engine
- New and powerful engine
- New and powerful engine
- New and powerful engine
- New and powerful engine
- New and powerful engine
- New and powerful engine
- New and powerful engine
- New and powerful engine
- New and powerful engine
Download pdf
Click the button below to download the video of the procedure below.
Product Description
||MA I N F E AT U R E S
• Selectable Wiegand output formats using the Hardware Con guration Tool
• Mounting options include US gangbox and UK/Asia gangbox.
• NFC Smartphone is supported
• Read the CSN from the following smart cards:
– IS014443A – MIFARE Ultralight Nano / Ultralight EVI / Ultralight C
– MIFARE Classic / Classic EVI
– MIFARE Plus S / SE / X / EVI
– MIFARE DESFire EVI / EV2
|| S P E C I F I C AT I O N S
• • Read Range: 125 KHz: 5 cm, 13.56 MHz: 2 cm
• • Reader Data Output Formats: CSN Wiegand 26/37 Bit and OSDP
• • Zinc Alloy case, Weather-resistant IP68, Vandal-proof IK10
• • Operating Voltage Range: 12 VDC with 10% tolerance
• • Idle Current at 12 VDC: Maximum 35 mA
• • Operating Temperature Range: -20 °C to 50 °C
• • Operating Humidity Range: to 95% (non-condensing)
• • Dimensions (hxwxd): 103x48x22 mm (S Model) / 120x83x22.5 mm (Max Model)
|| O P T I O N S
• Open Standard Device Protocol (OSDP)
• Support IS015693 – HID iClass, PicoPass, iCode, LEGIC
• Support IS018092 – SONY Felica
